应用描述Application Description
本机主要实现对锂电池高精密测漏;
This machine mainly realizes high precision leak detection of lithium battery;
功能特点:Functional characteristics:
整机布局合理紧凑、美观、上档次
The layout of the whole machine is reasonable and compact and beautiful
系统采用PLC自动控制,运行稳定,关键部件采用进口品牌
The system is controlled by PLC and runs stably. The key components are imported brands.
同时兼具大漏和小漏顺序自动检测,检漏参数设置灵活、检测效率高;
The invention has the advantages of large leakage and small leakage sequence automatic detection, flexible leakage detection parameter setting and high detection efficiency;
本机可嵌入产线或单机独立运行,多工位检测可使用模组或机械手进行上下料,方便操作、维护方便;
This machine can be embedded into the production line or stand-alone operation, multi-station detection can use modules or manipulators for loading and unloading, convenient operation, easy maintenance
检测数据后台自动存储,系统预留数据接口,方便MES系统对接;
The data background of the detection data is automatically stored, the data interface of the system is reserved, and the MES system is convenient to interface;
系统描述:System description:
系统主要有:上下料系统、输送系统、氦质谱等系统高度集成。
The main system is: loading and unloading system, conveying system, helium mass spectrometry and other systems highly integrated.
技术参数technical parameter
净尺寸 | 最大漏率 | |
系统占地面积System floor area | 4200×1800×1900 | 1×10-6Pa·m³/S |
真空舱性能Vacuum tank performance | (内腔净尺寸,可根据方壳尺寸定制) | 5.2×10-7Pa·m³/S |
氦质谱性能Helium mass spectrum performance | 393×547×375 | 5.2×10-8Pa·m³/S |
抽充氦气真空系统Pumping helium vacuum system | 5.2×10-7Pa·m³/S | |
功率Power | ||
节拍Time | 可根据生产需求设定Can be set according to production requirement |
