产品特点(Characteristics / Advantages):
1. 专为镍氢电池设计,完美发挥电池功效。
2. 适用温度范围宽泛,可以在-40至+70℃下充放电。
3. 可以根据时间、行人的数量来调整其功率、亮度、曝光范围等。
参数示例(Parameter Example):
Charging Current | ≤10A | |
Rated Operating Voltage | DC12V/24V (Adaptive) | |
Battery Input Voltage | 10~34V | |
Output Current Range | 0.1~10A | |
Average Output Current | ≤5A | |
Max. Solar Voltage Voc | DC80V | |
Output Voltage | 15~70V(12V System) | |
Output Voltage | 29~70V(24V System) | |
Battery Over-discharge Protection Voltage | 9.5V/19V | Adjustable |
Battery Pack Over-discharge Recovery Voltage | 11.6V/23.2V | Adjustable |
Charging Mode | MCT/CVT(Solar panel current tracking ) | |
Output Power | 60W(12V)/120W(24V) | |
Overload, Short circuit Protection | 2 times rated current automatically recovers in 5 minutes | |
Output boost function | 30V~50V | Adaptive |
Operating mode | Light control / light control + time control / debugging / morning light mode, support three time period settings | |
Working Environment | -40~70℃ |
